Salient Features
-
- Assured performance with low slump concrete too.
- Lower power consumption
- Best homogeneity
- Detachable charge hopper & split flow guide facilitate easy maintenance
- Higher safety during transit due to ANTI CLOCKWISE drum rotation for left side travel in India
- High speed charge / discharge performance due to its unique blade design
- High precision C shaped spirals are used prepared by accurate forming dies which helps in maintaining uniform and low resistance flow.
- Low center of gravity for better stability on rough roads
- High wear resistant steel drum and spirals
- Operator friendly
No. | Description | MR 60C |
DRUM | ||
1 | Geometric Volume | 11.1 |
2 | Nominal Capacity | 6 |
3 | Filling Ratio | 54 |
4 | Rotation Speed | 0 - 14 |
HYDRAULICS | ||
5 | Oil System Capacity | 16 |
WATER SYSTEM | ||
6 | Water Tank Capacity | 450 |
DIMENSIONS | ||
7 | Length of Mixer | 5590 |
8 | Height of Mixer | 2630 |
9 | Width of Mixer | 2350 |
ENGINE | ||
10 | Make | Kirloskar |
11 | Model | HA 494 |
12 | Power | 52 |
No. | Description | MR 60C PTO |
DRUM | ||
1 | Geometric Volume | 11.1 |
2 | Nominal Capacity | 6 |
3 | Filling Ratio | 54 |
4 | Rotation Speed | 0 - 14 |
HYDRAULICS | ||
5 | Oil System Capacity | 16 |
WATER SYSTEM | ||
6 | Water Tank Capacity | 450 |
DIMENSIONS | ||
7 | Length of Mixer | 5860 |
8 | Height of Mixer | 2630 |
9 | Width of Mixer | 2350 |
POWER | ||
10 | Power Take Off | PTO drive from truck chassis |
No. | Description | MR 70C |
DRUM | ||
1 | Geometric Volume | 12.1 |
2 | Nominal Capacity | 7 |
3 | Filling Ratio | 57.8 |
4 | Rotation Speed | 0 - 14 |
HYDRAULICS | ||
5 | Oil System Capacity | 16 |
WATER SYSTEM | ||
6 | Water Tank Capacity | 450 |
DIMENSIONS | ||
7 | Length of Mixer | 5840 |
8 | Height of Mixer | 2630 |
9 | Width of Mixer | 2350 |
ENGINE | ||
10 | Make | Kirloskar |
11 | Model | HA 494 |
12 | Power | 52 |
No. | Description | MR 70C PTO |
DRUM | ||
1 | Geometric Volume | 12.1 |
2 | Nominal Capacity | 7 |
3 | Filling Ratio | 57.8 |
4 | Rotation Speed | 0 - 14 |
HYDRAULICS | ||
5 | Oil System Capacity | 16 |
WATER SYSTEM | ||
6 | Water Tank Capacity | 450 |
DIMENSIONS | ||
7 | Length of Mixer | 6110 |
8 | Height of Mixer | 2630 |
9 | Width of Mixer | 2350 |
POWER | ||
10 | Power Take Off | PTO drive from truck chassis |
No. | Description | MR 80 |
DRUM | ||
1 | Geometric Volume | 14.4 |
2 | Nominal Capacity | 8 |
3 | Filling Ratio | 56 |
4 | Rotation Speed | 0 - 14 |
HYDRAULICS | ||
5 | Oil System Capacity | 17 |
WATER SYSTEM | ||
6 | Water Tank Capacity | 600 |
DIMENSIONS | ||
7 | Length of Mixer | 6990 |
8 | Height of Mixer | 2655 |
9 | Width of Mixer | 2350 |
ENGINE | ||
10 | Make | Kirloskar |
11 | Model | HA 694 |
12 | Power | 72 |
No. | Description | MR 80 PTO |
DRUM | ||
1 | Geometric Volume | 14.4 |
2 | Nominal Capacity | 8 |
3 | Filling Ratio | 56 |
4 | Rotation Speed | 0 - 14 |
HYDRAULICS | ||
5 | Oil System Capacity | 17 |
WATER SYSTEM | ||
6 | Water Tank Capacity | 600 |
DIMENSIONS | ||
7 | Length of Mixer | 6570 |
8 | Height of Mixer | 2655 |
9 | Width of Mixer | 2350 |
POWER | ||
10 | Power Take Off | PTO drive from truck chassis |
